Burgmann H74D Mechanical Seal
The FXH74D mechanical seal is a double-end face design. Through the design of two pairs of sealing faces, it has double-layer protection, which allows the mechanical seal to be used in more severe working conditions. It can perfectly replace the Burgmann H74D mechanical seal.
Description
Replacement for Burgmann H74D
1,Working Parameters
Temperature：-30~200℃
Pressure：≤2.5MPa
Speed：≤15m/s
2,Materials
Static ring：V1,Q1,Q2,Q3,U1,U2,A,B
Dynamic ring：Q1,Q2,Q3,U1,U2,A,B
Sealing ring：V,P,E,M1,K
Springs and structural parts：F,G,G1,M
3,Static Ring Type
Standard (material V1, Q1, Q2, Q3, U1, U2) with G9
Standard (material A, B) with G93
Replaceable: G6, G4
4,Applicable media: Clean water, sewage, oil, toxic and harmful media and other moderately corrosive media.
5,Description: The FXH74D mechanical seal is a double-end face design. Through the design of two pairs of sealing faces, it has double-layer protection, which allows the mechanical seal to be used in more severe working conditions. It can perfectly replace the Burgmann H74D mechanical seal.
The principle of this mechanical seal is that after the shaft rotates, the transmission sleeve is driven to rotate through the set screw, and the square groove of the transmission sleeve is used to drive the rotation of the moving rings at both ends. The seal between the shaft and the moving ring is maintained by the interference fit of the O-ring. The O-ring is stationary relative to the shaft, and contains a small spring. The small spring provides the initial seal of the mechanical seal and provides compensation for the moving ring during use. Multiple small springs make the force on the moving ring more uniform. The moving rings at both ends share a set of springs, making installation more convenient, thereby extending the service life of the mechanical seal. The sealing of the static ring is ensured by the interference fit of the O-ring, and the stationary state of the static ring is ensured by the friction of the O-ring. The static ring here has a pin added to it for anti-rotation function, which can better ensure the stationary state of the static ring. Flushing water should be passed through the middle to ensure the pressure inside, so as to better play a sealing role.
6,Our company has a strong design and development team, which can recommend and customize mechanical seal products that are more suitable for you according to different customer needs.
