Burgmann MG1 MG12 MG13 MGS20 Mechanical Seal

1,Working Parameters
Temperature：-20~150℃
Pressure：≤1.2MPa
Speed：≤10m/s

2,Materials
Static Ring：V1,Q1,Q2,Q3,U1,U2,A,B
Dynamic Ring：Q1,Q2,Q3,U1,U2,A,B
Rubber Parts：V,P,E,A
Springs and Structural Parts：F,G,G1,M

3,Applicable Media：Clean water, sewage, oil and other weakly corrosive media.

4,Directions：The FXMG mechanical seal is designed with a large spring transmission structure. It can effectively solve the problem of inconvenient screw tightening in a tight space and is easy to install.
This mechanical seal is an unbalanced large spring and large rubber design. It can effectively solve the problem of slight wear of the sleeve and space limitation.
The principle of this mechanical seal is that after the shaft rotates, the rubber holding the shaft rotates. The rubber is a whole, and the rotation of the dynamic ring is driven by the rubber, which better ensures the sealing of the rubber and the dynamic ring, and also increases the floating performance of the dynamic ring, which can well meet the sealing effect of the pump. The large spring provides the initial sealing of the mechanical seal and the compensation of the dynamic ring during use. The pitch of the large spring is relatively large, and it is not easy to block the spring in the medium containing a small amount of particles, thereby making the mechanical seal last longer.
The static ring part uses an L-shaped gasket to seal the static ring and the static assembly seat. Since the L-shaped gasket has a wider contact surface than the O-ring, it can better increase the friction of the static ring and ensure the sealing and stopping performance of the static ring.

5,Our company has a strong design and development team, which can recommend and customize mechanical seal products that are more suitable for you according to different customer needs.
